Specifications
- Manufacturer: Kawasaki
- Model: KLX140R Battle Gray
- Year: 2025
- Type: Off Road
- Engine: 144cc, air-cooled, 4-stroke, SOHC 2-valve single
- Bore x Stroke: 58.0 x 54.4 mm
- Compression Ratio: 9.5:1
- Fuel System: Carburettor: Keihin PB20
- Ignition: Digital DC-CDI
- Starting: Electric
- Lubrication: Forced lubrication, wet sump
- Transmission: 5-speed, return
- Clutch: Wet multi-disc, manual
- Final Drive: Chain
- Frame: Perimeter, box-section, high-tensile steel
- Front Suspension / Wheel Travel: ø33 mm telescopic fork / 180 mm (7.1 in)
- Rear Suspension / Wheel Travel: Uni Trak, single shock with adjustable spring preload / 180 mm (7.1 in)
- Rake / Trail: 27.0° / 85 mm
- Steering Angle (L/R): 41° / 41°
- Front Tire: 70/100-17 40M
- Rear Tire: 90/100-14 49M
- Front Brake: ø220 mm petal disc with dual-piston caliper
- Rear Brake: ø186 mm petal disc with single-piston caliper
- Dimensions (L x W x H): 1,820 x 790 x 1,050 mm (71.7 x 31.1 x 41.3 in)
- Wheelbase: 1,260 mm (49.6 in)
- Road Clearance: 235 mm (9.3 in)
- Seat Height: 780 mm (30.7 in)
- Curb Weight*: 93 kg (205 lb)
- Fuel Capacity: 5.8 litres
- Warranty: 6 months
- Kawasaki Protection Plus: 12 / 24 / 36 / 48 months
